Product Details:
Payment & Shipping Terms:
|
| Product Na40G QSFP Moduleme: | QSFP28 100G SR4 | PN: | ZXS-QPQ10GLW-00 |
|---|---|---|---|
| Product Line: | G30 | Speed: | 40G |
| Media Type: | Single-Mode Fiber (SMF) |
|---|---|
| Transceiver Type: | QSFP |
| TX Wavelength: | 1310 nm. |
| RX Wavelenght: | 1310 nm. |
| Minimum Optical Budget: | 6.7 dB |
| Maximum Distance: | 10km |
| Supported Data Rate: | 1.25-44.8 Gbps |
| Supported Applications: | 4 x InfiniBand QDR(10Gbps), 40G Ethernet (41.25Gbps), OTU3 (43.01Gbps), OTU3e2 (44.58Gbps) |
| DDM/DOM: | Supported |
| Temperature Range: | Standard 0°-70°C |
| Connectors: | Double LC |
| Tx Wavelength Bandwidth: | 4 WDM Seperated 1310nm Lanes (13 nm (1271, 1291, 1311, 1331)) |
| Rx Wavelength Bandwidth: | 4 WDM Seperated 1310nm Lanes (13nm (1271, 1291, 1311, 1331)) |
| Minimum Transmitting Power: | Each Lane -7 dB |
| Maximum Transmitting Power: | Each Lane 2.3 dB |
| Receiver Sensitivity: | Each Lane -13.7 dBm |
| Receiver Overload: | Each Lane 3.3 dBm |
| Transmitter Type: | DFB Laser |
| Receiver Type: | PIN photodiode |
| Power: | +3.3V single power supply |
| Chipset: | MAXIM, MINDSPEED, SEMTECH, UX |
| Compliance: | 802.3ba 40GBASE-LR4, CE, Class 1 FDA and IEC60825-1 Laser Safety Compliant, INF-8438i, RoHS, SFF-8436 |
