The an1100-d01 EoC data terminal is the access terminal device of the bidirectional data transmission access system of coaxial cable. An1100-d01 data terminal provides 4 Ethernet ports, and an1100-d01w data terminal provides 4 Ethernet ports +WIFI to ensure that each user's access bandwidth reaches more than 20Mbps, even if multiple people use it at the same time, they can enjoy the same fast transmission speed.
By matching the an5006-11/12 terminals, it demodulates the modulated signal sent by the header into a relatively low-speed parallel data stream, and then merges several parallel data streams into a high-speed serial data stream. Finally, we decrypt the data into standard Ethernet signals that we can use and send them to user data terminals (PC, IPTV set-top box, IP voice gateway, etc.) for use.
The an1100-d01 data terminal provides 300Mbps access bandwidth on the coaxial network and occupies the low frequency band below 70MHz, effectively avoiding the conflict with the frequency occupation of the existing CATV system and reducing mutual interference. In addition, it supports the existing tree and star CATV network, which has the advantages of long transmission distance, good network adaptability and high bandwidth, and is a powerful weapon for the deployment of data network in radio and television system
